Basic Usage of OmiCLIP Model

This notebook demonstrates the basic usage of OmiCLIP model, including loading model, encoding text and image, calculating similairty between image embeddings and text embeddings, and examples of preprocess ST data, scRNA-seq data, bulk RNA-seq data, and whole image. It takes about 30 mins to run this notebook using cpu on MacBook Pro.

[1]:

import os
import pandas as pd
import numpy as np
import scanpy as sc
import anndata
from PIL import Image

import loki.utils
import loki.preprocess

/opt/anaconda3/envs/loki_env/lib/python3.9/site-packages/timm/models/layers/__init__.py:48: FutureWarning: Importing from timm.models.layers is deprecated, please import via timm.layers
  warnings.warn(f"Importing from {__name__} is deprecated, please import via timm.layers", FutureWarning)

The sample data are stored in the directory data/basic_usage, which can be donwloaded from Google Drive link.

[2]:

data_dir = './data/basic_usage/'

Load OmiCLIP Model

The pretrained weights are avaliable on Hugging Face.

[3]:

model_path = os.path.join(data_dir, 'checkpoint.pt')
device = 'cpu'

[4]:

model, preprocess, tokenizer = loki.utils.load_model(model_path, device)

[5]:

model.eval()

[5]:

CoCa(
  (text): TextTransformer(
    (token_embedding): Embedding(49408, 768)
    (transformer): Transformer(
      (resblocks): ModuleList(
        (0-11): 12 x ResidualAttentionBlock(
          (ln_1): LayerNorm((768,), eps=1e-05, elementwise_affine=True)
          (attn): MultiheadAttention(
            (out_proj): NonDynamicallyQuantizableLinear(in_features=768, out_features=768, bias=True)
          )
          (ls_1): Identity()
          (ln_2): LayerNorm((768,), eps=1e-05, elementwise_affine=True)
          (mlp): Sequential(
            (c_fc): Linear(in_features=768, out_features=3072, bias=True)
            (gelu): GELU(approximate='none')
            (c_proj): Linear(in_features=3072, out_features=768, bias=True)
          )
          (ls_2): Identity()
        )
      )
    )
    (ln_final): LayerNorm((768,), eps=1e-05, elementwise_affine=True)
  )
  (visual): VisionTransformer(
    (conv1): Conv2d(3, 1024, kernel_size=(14, 14), stride=(14, 14), bias=False)
    (patch_dropout): Identity()
    (ln_pre): LayerNorm((1024,), eps=1e-05, elementwise_affine=True)
    (transformer): Transformer(
      (resblocks): ModuleList(
        (0-23): 24 x ResidualAttentionBlock(
          (ln_1): LayerNorm((1024,), eps=1e-05, elementwise_affine=True)
          (attn): MultiheadAttention(
            (out_proj): NonDynamicallyQuantizableLinear(in_features=1024, out_features=1024, bias=True)
          )
          (ls_1): Identity()
          (ln_2): LayerNorm((1024,), eps=1e-05, elementwise_affine=True)
          (mlp): Sequential(
            (c_fc): Linear(in_features=1024, out_features=4096, bias=True)
            (gelu): GELU(approximate='none')
            (c_proj): Linear(in_features=4096, out_features=1024, bias=True)
          )
          (ls_2): Identity()
        )
      )
    )
    (attn_pool): AttentionalPooler(
      (attn): MultiheadAttention(
        (out_proj): NonDynamicallyQuantizableLinear(in_features=768, out_features=768, bias=True)
      )
      (ln_q): LayerNorm((768,), eps=1e-05, elementwise_affine=True)
      (ln_k): LayerNorm((1024,), eps=1e-05, elementwise_affine=True)
    )
    (ln_post): LayerNorm((768,), eps=1e-05, elementwise_affine=True)
  )
  (text_decoder): MultimodalTransformer(
    (resblocks): ModuleList(
      (0-11): 12 x ResidualAttentionBlock(
        (ln_1): LayerNorm((768,), eps=1e-05, elementwise_affine=True)
        (attn): MultiheadAttention(
          (out_proj): NonDynamicallyQuantizableLinear(in_features=768, out_features=768, bias=True)
        )
        (ls_1): Identity()
        (ln_2): LayerNorm((768,), eps=1e-05, elementwise_affine=True)
        (mlp): Sequential(
          (c_fc): Linear(in_features=768, out_features=3072, bias=True)
          (gelu): GELU(approximate='none')
          (c_proj): Linear(in_features=3072, out_features=768, bias=True)
        )
        (ls_2): Identity()
      )
    )
    (cross_attn): ModuleList(
      (0-11): 12 x ResidualAttentionBlock(
        (ln_1): LayerNorm((768,), eps=1e-05, elementwise_affine=True)
        (attn): MultiheadAttention(
          (out_proj): NonDynamicallyQuantizableLinear(in_features=768, out_features=768, bias=True)
        )
        (ls_1): Identity()
        (ln_1_kv): LayerNorm((768,), eps=1e-05, elementwise_affine=True)
        (ln_2): LayerNorm((768,), eps=1e-05, elementwise_affine=True)
        (mlp): Sequential(
          (c_fc): Linear(in_features=768, out_features=3072, bias=True)
          (gelu): GELU(approximate='none')
          (c_proj): Linear(in_features=3072, out_features=768, bias=True)
        )
        (ls_2): Identity()
      )
    )
    (ln_final): LayerNorm((768,), eps=1e-05, elementwise_affine=True)
  )
)

Encode Image

Use OmiCLIP to encode image.

[6]:

image_path = os.path.join(data_dir, 'demo_data', 'TUM-TCGA-TLSHWGSQ.tif')
image = Image.open(image_path)

[6]:

../_images/notebooks_basic_usage_9_0.png

[7]:

image_embeddings = loki.utils.encode_images(model, preprocess, [image_path], device)
image_embeddings.shape

[7]:

torch.Size([1, 768])

Encode Text

Use OmiCLIP to encode text.

[8]:

text = ['TP53 EPCAM KRAS EGFR DEFA5 DEFA6 CEACAM5 CEA KRT18 KRT8 KRT19 CDH17 CK20 MYO6 TP53BP2 PLA2G2A CLDN7 TJP1 PKP3 DSP']
text_embeddings = loki.utils.encode_texts(model, tokenizer, text, device)
text_embeddings.shape

[8]:

torch.Size([1, 768])

Calculate Similarity

Calculate similairty between image embeddings and text embeddings.

[9]:

dot_similarity = image_embeddings @ text_embeddings.T

[10]:

dot_similarity

[10]:

tensor([[0.3926]])

Examples of preprocessing ST data, scRNA-seq data, bulk RNA-seq data, and whole image

Examples of using .h5ad object (ST data or scRNA-seq data) and .gct object (bulk RNA-seq data) to generate text embeddings, and examples of using whole image to generate image patch embeddings.

Encode transcriptome from AnnData object (ST data or scRNA-seq data)

Example of encoding transcriptome from .h5ad object. House keeping gene list is obtained from the Molecular Signatures Database (MSigDB): https://www.gsea-msigdb.org/gsea/msigdb/. It takes about 3 mins to run this section using cpu on MacBook Pro.

[11]:

ad_path = os.path.join(data_dir, 'demo_data', 'RZ_GT_P2.h5ad')
ad = sc.read_h5ad(ad_path)
ad

[11]:

AnnData object with n_obs × n_vars = 3538 × 14467
    obs: 'n_counts', 'n_genes', 'percent.mt', 'Adipocyte', 'Cardiomyocyte', 'Endothelial', 'Fibroblast', 'Lymphoid', 'Mast', 'Myeloid', 'Neuronal', 'Pericyte', 'Cycling.cells', 'vSMCs', 'cell_type_original', 'assay_ontology_term_id', 'cell_type_ontology_term_id', 'development_stage_ontology_term_id', 'disease_ontology_term_id', 'ethnicity_ontology_term_id', 'is_primary_data', 'organism_ontology_term_id', 'sex_ontology_term_id', 'tissue_ontology_term_id', 'leiden', 'pixel_y', 'pixel_x', 'cell_type'
    var: 'features'
    uns: 'X_approximate_distribution', 'X_normalization', 'default_embedding', 'leiden', 'neighbors', 'schema_version', 'spatial', 'title'
    obsm: 'X_pca', 'X_spatial', 'X_umap', 'spatial'
    obsp: 'connectivities', 'distances'

[12]:

house_keeping_genes = pd.read_csv(os.path.join(data_dir, 'demo_data', 'housekeeping_genes.csv'), index_col = 0)
top_k_genes_str = loki.preprocess.generate_gene_df(ad, house_keeping_genes)
top_k_genes_str

[12]:

	label
RZ_GT_P2_AAACAAGTATCTCCCA-1	TTN MYH7 MB MALAT1 MTRNR2L12 TPM1 DES CRYAB AP...
RZ_GT_P2_AAACAATCTACTAGCA-1	MYH7 MTRNR2L12 TTN CRYAB MYL2 MB TNNT2 DES TPM...
RZ_GT_P2_AAACACCAATAACTGC-1	TTN MYH7 MTRNR2L12 MB MALAT1 CRYAB TNNI3 DES A...
RZ_GT_P2_AAACAGAGCGACTCCT-1	TTN MYH7 MALAT1 MTRNR2L12 MYL2 MB TPM1 MYL3 CR...
RZ_GT_P2_AAACAGCTTTCAGAAG-1	MB MYH7 TTN CRYAB MTRNR2L12 TNNI3 TPM1 MYL2 DE...
...	...
RZ_GT_P2_TTGTTGTGTGTCAAGA-1	DES MB TCAP MYH7 TPM1 FN1 CMYA5 TNNI3 COL3A1 S...
RZ_GT_P2_TTGTTTCACATCCAGG-1	TTN MYH7 MTRNR2L12 MALAT1 MB CRYAB DES TNNC1 M...
RZ_GT_P2_TTGTTTCATTAGTCTA-1	TTN MALAT1 MYH7 MTRNR2L12 MB DES CRYAB TNNI3 T...
RZ_GT_P2_TTGTTTCCATACAACT-1	MTRNR2L12 MB MYH7 TTN CRYAB IGKC DES MALAT1 TP...
RZ_GT_P2_TTGTTTGTGTAAATTC-1	TTN MTRNR2L12 MYH7 TNNI3 MALAT1 MB DES CRYAB T...

3538 rows × 1 columns

[13]:

text_embeddings = loki.utils.encode_text_df(model, tokenizer, top_k_genes_str, 'label', device)
text_embeddings.shape

[13]:

torch.Size([3538, 768])

Encode transcriptome from GCT object (bulk RNA-seq data)

Example of encoding transcriptome from .gct object.

[14]:

sc_data_path = os.path.join(data_dir, 'demo_data', 'bulk_fibroblasts.gct')
gct_data = loki.preprocess.read_gct(sc_data_path)
gct_data

[14]:

	id	Name	Description	GTEX-111VG-0008-SM-5Q5BG	GTEX-111YS-0008-SM-5Q5BH	GTEX-1122O-0008-SM-5QGR2	GTEX-1128S-0008-SM-5Q5DP	GTEX-113IC-0008-SM-5QGRF	GTEX-113JC-0008-SM-5QGR6	GTEX-117XS-0008-SM-5Q5DQ	...	GTEX-ZVE2-0008-SM-51MRU	GTEX-ZVP2-0008-SM-51MSL	GTEX-ZVT2-0008-SM-57WC9	GTEX-ZVT3-0008-SM-51MRI	GTEX-ZVT4-0008-SM-57WCA	GTEX-ZVTK-0008-SM-57WDA	GTEX-ZVZP-0008-SM-51MSX	GTEX-ZVZQ-0008-SM-51MSK	GTEX-ZXES-0008-SM-57WCX	GTEX-ZXG5-0008-SM-57WDB
0	0	ENSG00000223972.5	DDX11L1	0	0	0	0	0	0	0	...	0	0	0	0	1	0	0	0	0	0
1	1	ENSG00000227232.5	WASH7P	21	31	16	41	57	46	66	...	24	62	40	42	64	58	62	52	20	32
2	2	ENSG00000278267.1	MIR6859-1	0	0	0	0	0	0	0	...	0	0	0	0	0	0	0	0	0	0
3	3	ENSG00000243485.5	MIR1302-2HG	0	0	0	0	1	0	0	...	1	0	0	0	1	0	0	1	0	0
4	4	ENSG00000237613.2	FAM138A	0	0	1	0	0	0	0	...	1	0	0	0	0	0	0	0	0	0
...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...
56195	56195	ENSG00000198695.2	MT-ND6	35691	34685	50128	81334	60140	81957	48581	...	60506	94854	76311	87410	63940	108716	70445	78721	68057	53557
56196	56196	ENSG00000210194.1	MT-TE	8	19	28	47	31	40	25	...	35	53	23	34	21	52	29	32	19	27
56197	56197	ENSG00000198727.2	MT-CYB	161038	154424	138836	246421	194695	225034	214565	...	269451	296274	335286	274560	186433	312236	499192	258581	241541	173705
56198	56198	ENSG00000210195.2	MT-TT	0	1	1	6	2	0	2	...	1	1	3	3	6	3	3	1	1	0
56199	56199	ENSG00000210196.2	MT-TP	3	0	0	3	1	0	3	...	1	0	1	1	7	4	1	0	1	2

56200 rows × 507 columns

[15]:

bulk_ad = anndata.AnnData(pd.DataFrame(gct_data.iloc[:, 3:].mean(axis=1)).T)
bulk_ad.var.index = gct_data['Description']
bulk_text_feature = loki.preprocess.generate_gene_df(bulk_ad, house_keeping_genes, todense=False)
bulk_text_feature

/opt/anaconda3/envs/loki_env/lib/python3.9/site-packages/anndata/_core/aligned_df.py:68: ImplicitModificationWarning: Transforming to str index.
  warnings.warn("Transforming to str index.", ImplicitModificationWarning)
/opt/anaconda3/envs/loki_env/lib/python3.9/site-packages/anndata/_core/aligned_df.py:68: ImplicitModificationWarning: Transforming to str index.
  warnings.warn("Transforming to str index.", ImplicitModificationWarning)

[15]:

	label
0	FN1 COL1A1 COL1A2 COL6A3 TGFBI THBS1 COL6A2 CO...

[16]:

text_embeddings = loki.utils.encode_text_df(model, tokenizer, bulk_text_feature, 'label', device)
text_embeddings.shape

[16]:

torch.Size([1, 768])

Encode patches from a whole image

Example of encoding patches from a whole image. It takes about 28 mins to run this section using cpu on MacBook Pro.

[17]:

coord = pd.read_csv(os.path.join(data_dir, 'demo_data', 'coord.csv'), index_col=0)
coord

[17]:

	pixel_x	pixel_y
GSM5924033_AAACAACGAATAGTTC-1	1579.906543	152.803738
GSM5924033_AAACAAGTATCTCCCA-1	478.504673	1266.355141
GSM5924033_AAACAATCTACTAGCA-1	1234.112151	219.626168
GSM5924033_AAACACCAATAACTGC-1	1541.121497	1467.289721
GSM5924033_AAACAGAGCGACTCCT-1	581.308412	464.485982
...	...	...
GSM5924033_TTGTTTCACATCCAGG-1	1246.728973	1444.859814
GSM5924033_TTGTTTCATTAGTCTA-1	1400.000001	1489.252338
GSM5924033_TTGTTTCCATACAACT-1	1438.785048	1155.140188
GSM5924033_TTGTTTGTATTACACG-1	1259.345795	1778.971964
GSM5924033_TTGTTTGTGTAAATTC-1	1131.775702	308.878505

4975 rows × 2 columns

[18]:

img = Image.open(os.path.join(data_dir, 'demo_data', 'whole_img.png'))

[18]:

../_images/notebooks_basic_usage_27_0.png

[19]:

img_array = np.asarray(img)
patch_dir = os.path.join(data_dir, 'demo_data', 'patch')
loki.preprocess.segment_patches(img_array, coord, patch_dir)

[20]:

img_list = os.listdir(patch_dir)
patch_paths = [os.path.join(patch_dir, fn) for fn in img_list]

[21]:

image_embeddings = loki.utils.encode_images(model, preprocess, patch_paths, device)
image_embeddings.shape

[21]:

torch.Size([4975, 768])

[ ]:
